CMM Programming

Request a quotation for program development or revision.

Request a quotation

StandardISO/IEC 17025:2017CoverageMissouri and the Greater Midwest

Quotation details are relayed by email.

A Program That Measures the Print

Running without error and measuring what the drawing requires are not the same thing. Datum structure, alignment strategy and GD&T interpretation are built from the print or model before a single point is taken.

Programs are developed offline against a CAD model or online at the machine, depending on fixture availability and part volume.

What Is Built

Each program covers feature strategy, probe and stylus selection and qualification, and the choice between scanning and discrete-point collection.

  • 01

    Platform-specific build

    Programs are written in PC-DMIS, Calypso, MODUS, CAMIO, PolyWorks or Quindos as the shop's software requires.

  • 02

    GD&T interpretation

    Datum reference frames and tolerance callouts are read directly from the print or model.

  • 03

    Stylus and probe strategy

    Stylus configuration and qualification are set before feature programming begins.

  • 04

    Reporting output

    Output is formatted for PPAP or first-article inspection submission.

Build Sequence

  • 01

    Print review

    Datums, tolerances and critical features are identified before programming starts.

  • 02

    Alignment

    Datum structure and part alignment strategy are built to match the drawing's reference frame.

  • 03

    Feature programming

    Discrete-point or scanning collection is assigned by feature type and tolerance.

  • 04

    Validation run

    The program is run and checked against known feature values before release.

Why St. Louis CMM Calibration and Repair

  • 01

    Shop-named platforms

    PC-DMIS, Calypso, MODUS, CAMIO, PolyWorks and Quindos, matched to what the shop already runs.

  • 02

    PPAP and first-article ready

    Reporting output is built for submission, not reformatted after the fact.

  • 03

    Print-driven, not model-only

    GD&T on the print governs the program even where the model disagrees.

Coverage across Missouri and the Greater Midwest

On-site service is scheduled across the metros and surrounding towns listed on this site. Machines outside that radius may still be served; ship-in arrangements are quoted on request.

Discuss CMM Programming Requirements

Send the print, model and target software platform.

Quotation details are relayed by email.
